Adding Multiple Items Using Kustomize JSON 6902 Patches
CloudRecently, I needed to deploy a Kubernetes cluster via Cluster API (CAPI) into a pre-existing AWS VPC. As I outlined in this post from September 2019, this entails modifying the CAPI manifest to include the VPC ID and any associated subnet IDs, as well as referencing existing security groups where needed. I knew that I could use the kustomize tool to make these changes in a declarative way, as I’d explored using kustomize with Cluster API manifests some time ago. This time, though, I needed to add a list of items, not just modify an existing value. In this post, I’ll show you how I used a JSON 6902 patch with kustomize to add a list of items to a CAPI manifest.
By the way, if you’re not familiar with kustomize, you may find my introduction to kustomize post to be helpful. Also, for those readers who are unfamiliar with JSON 6902 patches, the associated RFC is useful, as is this site.
In this particular case, the addition of the VPC ID and the subnet IDs were easily handled with a strategic merge patch that referenced the AWSCluster object. More challenging, though, was the reference to the existing security groups that I needed to add (necessary in order to use my existing SSH bastion infrastructure to reach CAPI-instantiated instances). In hindsight, I suppose I could have written a single strategic merge patch to do the same thing, but I went down the JSON 6902 patch route (and learned something along the way).
Here’s a snippet of what the final (rendered) YAML needed to look like (taken from an AWSMachineTemplate object in the CAPI manifest, the security group IDs are obviously fake):
spec: template: spec: additionalSecurityGroups: - id: sg-01234567890123456 - id: sg-abcdef0123456789a
The knowledge I was missing to make this work was how to correctly format the JSON 6902 patch such that it would add a list of items when rendered using kustomize. The jsonpatch.com site gave me the hint I needed—it just needed to be formatted like a JSON list. (It’s so obvious to me now, but I guess lots of things seem obvious after we learn them, right?)
Here’s a JSON 6902 patch that would create the YAML I was seeking:
[ { "op": "add", "path": "/spec/template/spec/additionalSecurityGroups", "value": [ { "id": "sg-01234567890123456" }, { "id": "sg-abcdef0123456789a" } ] }
]
The second useful piece to glean from this is something that I also mentioned in the post on using kustomize with CAPI, and that’s the use of a regular expression (regex) in the kustomization.yaml file to control where this JSON 6902 patch is applied. As outlined in the previous post on using existing AWS security groups with CAPI, the additionalSecurityGroups field can be added to an AWSMachineTemplate—this is exactly what I wanted so that both my MachineDeployments and my KubeadmControlPlane would pick up the change. So how do I get one patch to apply to multiple objects? With a regex, of course!
patchesJson6902: - path: securitygroups.json target: group: infrastructure.cluster.x-k8s.io kind: AWSMachineTemplate name: ".*" version: v1alpha3
The use of the .* regex for the name field means that kustomize will apply the referenced JSON 6902 patch to all objects that match the specified API group, kind, and API version. This is an extremely useful way to apply patches, and it’s not limited to JSON 6902 patches (which is why I said earlier I could have written a strategic merge patch instead).
Once I had the JSON 6902 patch file in place and the necessary changes to the kustomization.yaml file made, running kustomize build . created exactly the YAML I needed. Once I’d verified the correctness of the kustomize build ouptut, a quick kustomize build . | kubectl apply -f - set the creation of my workload cluster in action.
I hope this information proves useful to someone. If you have questions, or if you spot a mistake I’ve made in this post, feel free to reach out. I’m always open to constructive feedback. You can contact me on Twitter (DMs are open) or hit me up on the Kubernetes Slack. I’d love to hear from you.
…
